Nintex Workflow Migration Considerations

*This post was originally posted here.

Many companies are making the move from on-premises SharePoint to the cloud. There are many advantages of making the move – resource requirements are lessened, cost, features, accessibility, and more. It’s great once you are there, but the biggest challenge can be the work getting there. Migration to the cloud requires careful planning, knowledge and experience to take advantage of the cloud for the different types of content. Nintex Workflows are one of the best additions to Office 365 and migrating your existing on-premises workflows successfully isn’t a problem with the following considerations.

Missing Actions

Unfortunately, the cloud version of Nintex Workflows is not a 1-to-1 implementation of on-premises Nintex Workflow 2010 or 2013. The reason for this is because of Microsoft’s Workflow Manager model in Office 365 which does not support all of the actions from on-premises. At the time of this writing, there are 40 out-of-the-box Nintex actions unavailable in Nintex for Office 365. Custom workflow actions are also not supported. While most of the Nintex out-of-the-box actions have been replicated, they do not necessarily work the same as it does on-premises. This is due to the architectural differences between the two environments.

Nintex Workflow 2016 has the unique option of creating workflows that are fully compatible with Nintex Workflow for Office 365. As you begin to create a new workflow in SharePoint 2016, you can choose between creating an on-premises version with the extra 40 actions available or create an Office 365 compatible version that does not. While there are less actions available with the compatible option, it does ensure that your workflow will be compatible with Office 365 when you migrate.

SharePoint Online Limitations

There are also some key differences with SharePoint Online versus on-premises. One limitation is that a workflow file cannot not exceed 5MB in size after it is exported. When checking for a file size, know that a Nintex workflow is compressed when exported. To obtain the actual size, you will need to expand the NWP file to see what the total size is. Workflows exceeding this limit may have issues online. To reduce the risk of error, any large workflow may have to be rearchitected before moving to the cloud.

There are many other differences with the cloud that should be known. For example, one of the issues most clients run into is the immovable 5000 item List View Threshold limit. This is the maximum number of items that can exist in a list view and keep good performance. In SharePoint on-premises, an administrator can raise the limit or set Daily Time Windows where the limits are raised. In Office 365, this limit cannot be changed and is in place 24×7. It may be necessary to create new lists to address this issue which may affect workflows. This is one example where knowledge of the limitations within SharePoint Online is paramount to a successful migration.

Other Considerations

Because of the differences in Office 365, issues can arise with workflows when implementing features. Turning on something like two-factor authentication may cause significant issues with Nintex workflows.  Knowing the limitations of Nintex’s different implementations in relation to Office 365 features prevents downtime by using workarounds.

The architecture of your workflows should be reviewed. Some actions affect performance more than others (e.g. Execute SQL, Query LDAP, etc.). Excessive looping can significantly slow down, stall, or have their execution throttled. Unfortunately, you cannot modify or increase the hardware running the workflows like you could on-premises. Also, the SharePoint Online Workflow Engine controls workflow throttling which Nintex has no control over. The only option is to increase efficiency through design with the workflow.

How Do I Get There?

All of these considerations can seem very daunting when approaching a migration to the cloud for the first time. This stress is increased since the cloud is always changing. Finding experts that are focused on this activity with experience of various requirements with solutions can help mitigate the unknowns.

A third-party migration tool like Sharegate can greatly assist with the move. Sharegate works directly with Nintex to improve their ability to produce successful migrations. Sharegate will move all Nintex workflows, including those with actions that are not supported. Placeholders are put where the actions would normally be. The placeholders are labeled with the comments of the original action for easy identification.  This allows for a workaround to be developed within Office 365 which also helps with testing in the target environment.


Migrations are a complex process. The recipe for success is investigation of the existing environment, planning, knowledge of the current target environment, and a good 3rd-party tool. Experience with the cloud and tools involved is also desired. With that combination, getting your Nintex workflows to the cloud will be a success for you and your organization.

Capturing Comments for Nintex’s Lazy Approval in Office 365

*This post was originally posted here

Providing solutions for customers is always a win when you can improve communication between employees. With Nintex workflows, one of the challenges many developers have with Lazy Approval on Office 365 is capturing the comments provided by Approvers in the email back to the original submitter. A task email is sent to an Approver and that Approver can only reply with the approval/rejection keywords. Any other comments in the email will be disregarded by the system. Also, there is no option to CC the original submitter in the initial task email which means the only way for an Approver to email comments back to the original submitter is by manually copying them in the approval/rejection email. This would not allow the comments to be captured along with the task. Frustration with this issue can be seen on the Nintex UserVoice site where it is one of the top voted requests. While comments cannot easily be captured if the Approver replies by email, they can be captured if the Approver customizes the Nintex task form. Simply put, the comments are captured in a workflow variable and added to the body of the email.

To accomplish this, start by creating your form and workflow. For this example, I am using the simple workflow below:

The first step is to create the text variable that will capture the comments from the custom Nintex task form. Click “Variables” from the workflow ribbon and then click “New” to create the text variable. I’m calling mine “TaskComments”.

After that has been completed, go into your “Assign a task” action and click on the “Edit Task Form” button in the ribbon.

You will be presented with the standard Nintex form that you can customize. Next, create a panel at the bottom of the form and assign a rule to hide the panel at all times. The rule should have these settings:

Add a “Calculated Value” field to the panel. This field will assign the comment to the “TaskComments” variable we created earlier. Add the Named Control called “Comment” to the Formula and set the Connected to field to the variable “TaskComments”. The settings should look like this:

Save everything. Your form should now look something like this:

Now all that is left is to add the variable to our email. Go into your “Send an Email” action on the “Rejected” branch and add the “TaskComments” variable to the body of the email. It should look something like this:

Do the same with the Approved email and you’re done. Publish the workflow and you’re good to go!


Track and Visualize Compliance Events as Part of Nintex Workflows

This post was written for B&R Solutions

Like most consulting groups that build a lot of workflows for process automation, we work with a lot of approval processes to help formalize important reviews and decisions while supporting compliance activities.  We recently received an interesting request to update an existing process we helped build and maintain.  In this particular approval process, the financial transactions were being reviewed and approved, but the stakeholders really needed to be able to view the pending and approved transactions.

Adding a calendar to visualize when approvals have taken place was a big win with the client. The requirements for setting it up were simple. The events would have either a ‘Pending’ or ‘Approved’ state and can approve via email. Finally, the events would appear on a calendar color-coded to each state of approval.  Because the pending documents are stored in a separate library from final documents, and to support color coding and full featured calendar connections, we chose to use a calendar list versus the limited calendar view format for a traditional SharePoint library.

Nintex’s LazyApproval is a great solution for approval workflows. Setting up the workflow was simple. Once a user adds a new document and sets the event date, the workflow creates a calendar event and then creates a task. The first step in the workflow is a filter to check if the Created date is equal to the Modified date. This lets me know if the item was just added to the library without having any metadata added to it. I could check to see if a calendar item has already been created. This would occur if an item had already been rejected and updates have been applied to the original item. If not, the calendar item is created in the ‘Pending’ state. On approval, the calendar item is set to ‘Approved’. If rejected, it will stay as ‘Pending’.

The workflow looks like this:

The way I keep the Calendar Events in sync with the documents is by using the Document ID. I added a text field called “Document ID” and write the Document ID value on creation of the calendar item. That makes it easy to query.

Setting up the calendar requires a trick in the use of the ribbon option ‘Calendar Overlay’.

Normally, separate SharePoint calendars are used to overlay onto a single calendar. Using that method, 3 separate calendars would be required for this solution, one for each state of the event. The trick is to add a separate calendar view as a separate calendar. By using this method, there is no need for separate calendars, only for separate calendar views.

Once you enter your site into the Web URL and click ‘Resolve’, the List and List View dropdowns should populate. Simply choose them and when your calendar items meet the criteria for the list view, they will appear with the color you chose.

The result is a single calendar with multiple color-coded entries. Events can even span multiple days or specific times depending on your start/end dates and times.

While this is just a subset of the total workflow, it illustrates a great technique that can be used for supporting your compliance activities. Creative uses of workflows with SharePoint apps help demonstrate the full power of the platform as well as their investment to the client generating a win on many levels.  Utilizing what is available in the box combined with thinking out of the box is key to happy clients.

Gmail scripts – Mark Read During Business Hours

I quickly threw this together. The following script would mark all Gmail email coming in to be read if it’s Monday through Friday between the hours of 9am and 5pm. This is done at with the API from

Don’t forget to click on Resources > Current Project’s Triggers and have it run once a minute!

function markReadDuringBusHours() {
    var currentDate = new Date();
    var currentDay = currentDate.getDay();
    var currentHour = currentDate.getHours();
    var threads = GmailApp.getInboxThreads();
    if (currentHour > 8 && currentHour < 18 && currentDay > 0 && currentDay < 6)

Speed Up iPhoto ’09 Launch Time

This comes from the site.

The start time in  iPhoto '09 can take minutes if you have a really large database of photo (like 30k plus). But even if you have a small database, this will still speed up your launch time.

How To

Open Terminal and type:  cd "~/Pictures/iPhoto Library"

Then execute the following command: for dbase in *.db; do sqlite3 $dbase "vacuum;"; done


That's it! You should notice an improvement in your startup time.
